Data UI Blocks

Next Gen UI Agent produces UI components for InputData passed to it, to visualize the data the best as possible. We call this output Data UI Blocks.

Different types of Data UI Blocks can be used, depending on how are UI components selected and configured. For now these types are available:

Dynamic components - fully dynamic components we provide UI rendering code for
Hand build components - you have to provide own UI rendering code

Selection and Configuration process

UI Agent provides flexible and highly configurable UI component selection and configuration process to serve distinct use cases. It ranges from fully LLM powered selection and configuration to tightly, per input data type, configured components, without LLM need.

The process goes over these steps in this order:

Hand Build Component requested in InputData - no LLM required
When InputData.type is set, component can be defined for it in the agent config:
1. Single component configured:
  - Hand Build Component - no LLM required
  - pre-configured Dynamic Component - no LLM required
2. Multiple components configured - LLM selects best option:
  - LLM powered selection from configured Dynamic Components (with or without pre-configuration)
  - HBCs can be mixed with other components, each HBC must have prompt.description defined so LLM knows how to select it
  - Configuration generation for Dynamic Components is controlled by llm_configure flag:
    - llm_configure=true (default): LLM selects component AND generates configuration
    - llm_configure=false: LLM only selects component, uses pre-defined configuration
  - LLM System prompt contains only configured components for focused selection
  - Each component can have custom prompt configuration to override default one for better LLM fine-tuning.
Fully LLM selected and configured Dynamic Component - LLM selects from all available components

If only "no LLM required" use cases are used in your deployment (step 1 and 2.1), the UI Agent can be instantiated without LLM (without LLM Inference provider).

UI Agent by default selects from all the supported Dynamic Components in step 3, but you can narrow choice to the components suitable for your application in the configuration.

Note that InputData.type often contains name of the LLM tool used to load the data (eg. in our AI framework bindings), so tool names are directly used for binding to UI components in this case.

Example configuration

In the case of this example yaml configuration, selection and configuration works this way:

For input data with type=movies:movie-detail, Hand Build Component with name movies:movie-detail-view is used. Its specific rendering code has to be provided in used UI renderer.
For input data with type=movie:movies-list, table Dynamic Component is used, configured to show three columns and "Movies" title.
For input data with type=movie:actors-list, LLM selects between table and set-of-cards based on user prompt and data. Table uses pre-configured fields, cards are fully configured by LLM.
For other input data, AI/LLM powered selection and configuration is performed from all available components.

---
data_types:
  movies:movie-detail:
    components:
      - component: movies:movie-detail-view

  movie:movies-list:
    components:
      - component: table
        configuration:
          title: "Movies"
          fields:
            - name: "Name"
              data_path: "$..movies[].name"
            - name: "Year"
              data_path: "$..movies[].year"
            - name: "IMDB Rating"
              data_path: "$..movies[].imdb.rating"

  movie:actors-list:
    components:
      # LLM selects best option based on user prompt and data
      - component: table
        llm_configure: false  # Use pre-configured fields
        configuration:
          title: "Actors"
          fields:
            - name: "Name"
              data_path: "$..actors[].name"
            - name: "Age"
              data_path: "$..actors[].age"
      - component: set-of-cards
        llm_configure: true  # LLM generates fields

Prompt Customization for Component Selection

For agent decisions, the LLM uses system prompt to select the best component based on the user's query and data and configure it. This prompt can be customized at multiple levels with increasing specificity.

This section focuses on component-specific prompt customization (component descriptions, chart instructions, configuration examples). For customizing the initial system prompt sections (rules, instructions, strategy-specific prompts), see Prompt Tuning.

Prompt Override Precedence

Prompts are constructed by merging overrides in this order (later overrides replace earlier ones):

Base prompts: Default component prompts hardcoded in the agent, see COMPONENT_METADATA
Global prompt overrides: From config.prompt fields - applies to all data types
Per-data-type prompt overrides: From config.data_types[type].prompt fields - applies to specific data type (NEW)
Per-component prompt overrides: From data_types[type].components[component].prompt - applies only to this component in this InputData.type

Note: Per-component overrides (level 4) only affect component-specific fields (description, chart_, twostep_step2configure_), while per-data-type overrides (level 3) affect the overall system prompt structure, examples, and chart instructions.

Warning

Please be aware that one large system prompt is constructed by the UI Agent using these per-component overrides, but also common parts. Final inference results heavily depend on used LLM type, for some change of one component system prompt may also affect other components or overal agent's performance. Mainly smaller LLMs are more sensitive on system prompt changes and interdependencies in it. Always use the evaluation tool, and ideally your project specific evaluation dataset, to measure agent's performance when tuning system prompt this way. It is always a good idea to start with default prompts fields from COMPONENT_METADATA and gradually fine-tune them while measuring agent's performance.

Configuration Example

# Global prompt customization (applies everywhere)
prompt:
  components:
    table:
      description: "Use table to show multiple items"

data_types:
  movie-data:
    components:
      # This table uses per-component override (takes precedence)
      - component: table
        prompt:
          description: "Use table for movie listings with many items but without actors"
          twostep_step2configure_rules: "Always include title and year fields."

      # HBC with required description
      - component: movies:list-with-actors
        prompt:
          description: "Use this component if user wants to see movies with actors."

      # Cards uses global prompt (no per-component override)
      - component: set-of-cards

Prompt customization fields by Component Type

Different component types use different prompt customization fields:

All components: description - Main description for component selection. It should
Dynamic components: twostep_step2configure_example, twostep_step2configure_rules - Field selection guidance used by two-step strategy only
Dynamic Chart components: chart_description, chart_fields_spec, chart_rules, chart_inline_examples - Chart-specific guidance

For Hand-Build Components (HBCs): - Only description field is used for LLM component selection, chart_* and twostep_step2configure_* fields are not used for HBCs. - When multiple components include HBCs, each HBC must have prompt.description defined

Per-Data-Type Prompt Customization

In addition to per-component prompt customization described above, you can customize the overall system prompt structure, examples, and chart instructions on a per-data-type basis. This is useful when different data types (typically from different tools or data sources) require different prompting strategies.

Available Fields

All fields from AgentConfigPromptBase can be customized per data type (everything from global prompt configuration except components):

system_prompt_start: Override initial system prompt for one-step strategy
chart_instructions_template: Override chart instructions template
examples_normalcomponents: Override normal component examples (one-step)
examples_charts: Override chart component examples (one-step)
twostep_step1select_system_prompt_start: Override initial prompt for two-step strategy step1
twostep_step2configure_system_prompt_start: Override initial prompt for two-step strategy step2
twostep_step1select_examples_normalcomponents: Override normal component examples (two-step step1)
twostep_step1select_examples_charts: Override chart component examples (two-step step1)

Precedence Order

For system prompt construction: 1. Data-type specific prompt (highest priority) 2. Global prompt from config.prompt 3. Default hardcoded prompt (lowest priority)

Configuration Example

# Global prompt configuration
prompt:
  system_prompt_start: |
    You are a generic UI assistant.

    AVAILABLE UI COMPONENTS:
  examples_normalcomponents: |
    Generic table example:
    {"component": "table", "title": "Items"}

data_types:
  # Tool A data with specific prompt requirements
  tool-a:result:
    prompt:
      system_prompt_start: |
        You are a Tool A data visualization assistant.
        Focus on key metrics and trends.

        AVAILABLE UI COMPONENTS:
      examples_normalcomponents: |
        Tool A table example with metrics:
        {"component": "table", "title": "Tool A Metrics"}
    components:
      - component: table
      - component: chart-bar

  # Tool B data with different prompt strategy
  tool-b:result:
    prompt:
      system_prompt_start: |
        You are a Tool B data visualization assistant.
        Emphasize relationships and hierarchies.

        AVAILABLE UI COMPONENTS:
      chart_instructions_template: |
        Tool B specific chart guidance:
        {charts_description}
    components:
      - component: table
      - component: set-of-cards

  # Tool C uses global prompts (no data-type override)
  tool-c:result:
    components:
      - component: one-card

In this example: - tool-a:result data uses Tool A specific prompts and examples - tool-b:result data uses Tool B specific prompts with custom chart instructions - tool-c:result data falls back to global prompts - Other data types without configuration use global prompts

Use Cases

Per-data-type prompt customization is particularly useful for:

Different Tool Outputs: When integrating multiple tools, each tool's output may benefit from domain-specific prompting
Data Source Variations: Different data sources (databases, APIs, files) may need different visualization strategies
Multi-Tenant Applications: Different tenants or customers may have different visualization preferences
A/B Testing: Test different prompting strategies for the same data type
Language/Locale Variations: Provide prompts in different languages for different data types

Best Practices

Start with Global: Define global prompts first, then override only what's necessary per data type
Test Thoroughly: Use the evaluation tool to measure impact
Document Rationale: Comment why specific data types need custom prompts
Combine with Per-Component: Use both per-data-type AND per-component customization for fine-grained control
Monitor Performance: Small LLMs are more sensitive to prompt changes - validate with your target LLM

How Prompts Are Used

The system prompt construction process (for multi-component scenarios):

Component lookup: Strategy determines which components are available for the processed InputData.type
Prompt metadata merging: Applies base → global → per-input-data-type-component prompt overrides
Caching: Caches the system prompt using InputData.type as key for performance
LLM selection: LLM uses the customized system prompt to select best component

This allows you to: - Fine-tune component selection per input data type (typically tool call loading data) - Provide domain-specific guidance for component usage - Mix HBCs with dynamic components when appropriate - Maintain different component selection criteria for different input data types
